Basic Info

Model No.: JH-EE2

Type: Buggy/Golf Carts, Ezgo Golf Cart

Seats: 1-2

Power Fuel: Electric

Maximum Speed: >30 km/h

Gradeability: 20-30%

Suitable for: Golf Course

Certification: EPA, ISO, CE, CE

Voltage of Battery: 48V

Color: Beige, Customized

Battery Voltage: 48V

Description: 2 Seater Electric EZGO Golf Cart

Place Of Origin: Zhejiang

Motor: 48V 4KW

Controller: Crutis/Chinese Top Brand Inpower

Fuel Type: Electric

Used For: Beach Resort,golf Course ,golf Club ,sea Island Resort

Additional Info

Packaging: Iron packing

Productivity: 400 units per month

Brand: jinghang

Transportation: Ocean

Place of Origin: china

Supply Ability: 400units / month

Certificate: CE,ISO

HS Code: 8703101900

Port: Ningbo,Shanghai

Product Description

Powerful golf cart off road wholesale mini gasoline carts
Electric golf cart modle  with 2 seats ,that apperence  can been changed to other types(Like ezgo,yamaha and club car) .our factory also can offer OEM service.can print /past your company logo on the golf cart.

                                            Main specifications for battery power

Motor:                                  3kw DC or 4kw AC Motor             Controller:  Imported Curtis Controller, 275A-400A

Battery:                                48v 150ah  Six cells 8-volt deep cycle storage battery

Battery lifespan:                    More than 700times charge cycles (for standard battery)

Charger:                               100-240v intelligent pulse charge with the function to recover the battery

Charging time:                      8-10 hours

Brake System:                      Rear mechanical drum brake plus pedal park brake, electric brake

Transimission:                      Motor Shaft Direct Drive

Range per charge:                More than 90kms                            Max.speed:    29km/h

Max.climbing:                      30%(full loaded)                            Curb weight:    430kgs

                                                         Main Specifications for gas power

Engine:                             250cc GY6, Water cooled, 4 stroke, single cylinder

Horse power &Torque:       17HP(12.5KW),  17.6N.m                        Drive Train:     CVT(F-N-R)

Fuel tank:                          7L                                            Range per full tank:     More than 200kms

Transimission:                    Shaft drive                                       Brake System:     Front&rear hydraulic

Max.speed:                        29km/h                                            Curb weight:     340kgs

Max.climbing:                     40%(full loaded)

                                                                   Common Specfications

Passenger:                          2 persons

Frame:                                Welded steel with double coating (galvanized frame is a option)

Windshield:                         Tempered glass( unfoldable), Organic glass(Foldable or unfuldable)

Color:                                 Any color as requirements(we also accept custom colors)

Steering:                             Self-compensating rack and pinion

Suspension:                         heavy duty leaf spring with dumper&spring absorber

Accelerator:                         stepless speed change

Rear Axle:                           Differential  model                                Start way:      Electric start with key

F&R tyre:                            18/8.8-8 inch tubless with with iron rim

Brake Distance:                   ≤4M                                                 Max.loading :     400kgs

Overall  dimensions:            2300*1200*1710mm             Min ground clearance:     127mm

Wheelbase:                        1640mm                                              F&R Tread:     840mm/985mm

Packing size:                      2300x1200x950mm

Packing:                             With irom Rack(Pack with roof ,seats,steering,,dissambled)

Loading:                            10units /20ft container, 20units /40GP container, 30units / 40HQ container

Lights:                               Head lights, night lights,tail lights,brake nights,turnning lights

Packing&Loading

Company informations

Yongkang jinghang sightseeing vehicle co.,ltd specialized ln designing and producing gas and electric golf carts,sightseeing cars since 2002 which is one of the earliest factory in this industry in china, our factory make the frame and do the paintting by ourself, we produce gas golf cart since 2005 and currenty we are the only factory producing gas golf carts maturely in china, most of our workers are very experienced, skilled that followed the factory for many years, we also accept many kinds OEM service.

Certification

Our Advantages

1: Competitive factory prices, many types(like ezgo, club car and yamaha types) for your choice.

2: Professional and direct&fast factory after service supported.

3: Both gas powered and battery powered offered for your choice

4: Earliest factory in industry,experienced and skilled workers, stable quality and good craftmanship.

5: Strong production ability that enable fast and punctual delivery of your orders.

6: Many of the OEM services are acceptable as required.

Customers show

1.What Extra Optionals do you have for this golf carts?

Different body colors, Seat belts, Rear cargo box, Inner rear view mirror, Rain cover, sunshine Cover,Rear flip seats, aluminum chasis, front mounted basket, gps tracker, Usb Music player, or any other optionals as  your requirement!

2. warranty time?

2Years

3.How do you test the finished products before shipping?

For the test, we have dedicated test peoples,we do initial test at factory and after that we will test them by climbing the 45 degree(for gas power) rough moutain slope and long way driving to make sure the really work well before loading!

 4. How is your after service work?

We have dedicated after sale staffs that can have offer you professional answers or technical questions upon your requirements!

5.Do you offer OEM service?

 Yes .

6.What is your Delivery time?

 7-25days

7.What payment term do you accept?

T/T, L/C, Aliababa Trade Assurance,,,etc

8.What is your delivery Method?

We Normally deliver by sea.
