China Manufacturer EAF ARC Furnace Graphite Electrode UHP 200-700mm Graphite Electrode Price

Min. Order:	3
Price:	900-1600
Port:	China
Place of Origin:	Ningbo,China
Settlement Method:	L/C
Transportation Method:	Shipping
Company:	Handan Zhongling Technology Co., Ltd.
Contacts:	Boss Cui
Mail:	admin@zhonglingmetal.com
Phone:	15531003199
Website:	www.zhonglingtechnology.com
PV:	284

Contact Supplier

Leaving a message

Mr. Boss Cui

Supplier

Email： admin@zhonglingmetal.com

Country/Region： Zhejiang China

Mobile Number： 15531003199

Handan Zhongling Technology Co., Ltd.

Personal Center

Product Description Company Profile Message information

Model Number	ZL-04- EAF ARC graphite electrode
Brand Name	ZL
origin	China
Small Orders	Accepted

Key Specifications/ Special Features:

Graphite electrodes are used mainly in ladle furnaces, electric-arc furnace steelmaking, Yellow phosphorus furnace, Industrial silicon furnace or melting copper. They are presently the only products available that have high levels of electrical conductivity and the capability of sustaining the extremely high levels of heat generated in this demanding environment. High-Quality Needle Coke in HP&UHP graphite electrode, ensure the electrode application is perfect. Graphite electrodes are also used to refine steel in ladle furnaces and in other smelting processes.

Graphite electrode has the advantages of low resistivity,high electrical conductivity and thermal conductivity,good oxidation resistance, good thermal shock resistance,high mechanical strength,easy to machine,etc.
1. Low electric resistance
2. Good electric and thermal conductivity
3. High density
4. High anti-oxidation capability
5. High mechanical strength
6. High machining accuracy

China Manufacturer EAF ARC Furnace Graphite Electrode UHP 200-700mm Graphite Electrode Price supplier

Size: Diameter ranges from 50 to 1200mm, Length from 1500 to 2400mm.

Application: Electric arc furnaces, ladle furnaces and submerged arc furnaces for steel making and yellow phosphorous production.

China Manufacturer EAF ARC Furnace Graphite Electrode UHP 200-700mm Graphite Electrode Price supplier

Grades Available: RP, HP, SHP, UHP graphite electrodes and nipples.

Special Treatment: Anti-oxidation impregnation treatment to prolong graphite electrodes service life and reduce consumption rate.

China Manufacturer EAF ARC Furnace Graphite Electrode UHP 200-700mm Graphite Electrode Price supplier

ITEM		UNIT	RP	HP		UHP
ITEM		UNIT	3-24inch Ф75-600mm	4-24inch Ф100-300mm	14-24inch Ф350-600mm	12-20inch Ф300-500mm	22-28inch Ф550-700mm
Resistivity	Electrode	μΩ·m	7.0-9.0	5.8-6.8	5.5-6.5	4.8-5.8	4.5-5.5
Resistivity	Nipple	μΩ·m	4.0-4.5	4.0-5.0	3.5-4.0	3.0-4.0	2.5-3.5
Bending Stregth	Electrode	Mpa	7.0-12.0	9.0-12.0	10.0-14.0	10.0-15.0	12.0-16.0
Bending Stregth	Nipple	Mpa	19.0-22.0	16.0-20.0	20.3-23.0	20.0-24.0	22.0-25.0
Elastic Modulus	Electrode	Gpa	7.0-11.0	8.0-12.0	8.0-12.0	9.0-13.0	10.0-14.0
Elastic Modulus	Nipple	Gpa	12.0-14.0	12.0-15.0	14.0-16.0	15.0-18.0	16.0-19.0
Bulk Density	Electrode	g/cm³	1.60-1.65	1.68-1.70	1.68-1.72	1.70-1.75	1.70-1.75
Bulk Density	Nipple	g/cm³	1.75-1.80	1.78-1.82	1.78-1.82	1.78-1.85	1.8-1.85
Ash	Electrode	%	0.3	0.3	0.3	0.2	0.2
Ash	Nipple	%	0.3	0.3	0.3	0.2	0.2
CTE	Electrode	10-⁶/℃	2.0-2.4	1.6-2.0	1.6-1.9	1.1-1.4	1.1-1.4
CTE	Nipple	100-600℃	1.8-2.2	1.1-1.5	1.1-1.4	0.9-1.2	0.9-1.2

FAQ:

1. Q: When can I get the price?

A: We usually quote within 24 hours after getting your detailed requirements, like size,
quantity etc. If it is an urgent order,we will be grateful for your prompt calling.

2. Q: What is the lead time for mass product?

A: The lead time is based on the quantity, about 2-4 weeks if we have ready cargo.
For graphite product, to apply Dual-use items license need about 15-20 working days.

3.Q: What is the term of the delivery?

A: FOB, CFR, CIF, etc.

4.Q: Notice

A: Please note that the price on globalsourse is a rough price.The actual price will depends on
sizes, grade, raw materials, and order quantity.
